GSM Antenna roof mount multi band

Multi band roof antenna  ( GSM, DCS, PCS, AMPS, UMTS )

The multi band antenna can be mounted on roof by screwing.

GSM antenna general data

• Dimensions (mm): 67 x 29
• Temperature range: -40^o C to +85^o C
• Coaxial cable GSM/UMTS/WIFI: RG 174 4000 mm FME/F
• Other cable length, cable type or coaxial connector upon request
• Customised colour of plastic enclosure or customised frequency range upon request

Technical data celluar / 2400 MHz band

• Frequency range:
• GSM 850 / 900: 824 - 960 MHz
• GSM 1800: 1710 - 1880 MHz
• GSM 1900 / UMTS: 1920 - 2170 MHz
• Bluetooth / WLAN / ZigBee 2400 - 2500 GHz
• Impedance: 50 Ohm
• Max power: 100 W
• VSWR: <1.5 / 2.0 (depends on band)
• Gain: 0 dBi
