GSM Directive Outdoor Antenna Quad 850/ 900 / 1800 /1900

Directive Quad band roof antenna  ( GSM, DCS, PCS, AMPS, UMTS )

This directive Quad band antenna can be mounted on the wall by screwing. It offers you a high gain ( 10dbi) by using of a planar structure.

GSM antenna general data

• Dimensions (mm): 162 x 142 x 45
• Temperature range: -30^o C to +80^o C
• Coaxial cable GSM/UMTS: C0100 5000 mm FME/F
• Other cable length, cable type or coaxial connector upon request
• Customised colour of plastic enclosure or customised frequency range upon request

Technical data celluar / 2400 MHz band

• Frequency range:
• GSM 850 / 900: 824 - 960 MHz
• GSM 1800: 1710 - 1880 MHz
• GSM 1900 / UMTS: 1920 - 2170 MHz
• Impedance: 50 Ohm
• Max power: 50 W
• VSWR: <1.5
• Gain: 10 dBi
